Request a quote on stock# 4505| Specification | Description |
|---|---|
| MANUFACTURED NEW | 1982 |
| SWING OVER BED, MAX. | 31" |
| SWING OVER CROSS SLIDE, MAX. | 21" |
| DISTANCE BETWEEN CENTERS, MAX. | 63" |
| SPINDLE SPEED RANGE | 2 - 1200 RPM |
| SPINDLE BORE | 4.6" |
| RAPID TRAVERSE RATE (X & Z) | 237 IPM |
| SPINDLE MOTOR | 60 HP |
| TOOL TURRET-1, VERTICAL, FRONT | 8 POSITION, AUTO INDEXING |
| TOOL TURRET-2, HORIZONTAL, REAR | 4 POSITION |
| WEIGHT, APPROX. | 24,000 LBS |
| DIMENSIONS, APPROX. | 14'L x 7.5"W x 6'H |
